Model | HW-M8-102/87F |
Number of Placement Heads | 8(high-accuracy) |
Number of iC Trays | 96 |
Number of Feeders | 102/87(subject to 8mm feeder) |
Positioning Accuracy | 0.01mm |
Repeated Mounting Accuracy | 0.02mm |
Range of Mounting Speed | 20000-27000/CPH |
Applicable Components | Resistor/capacitor/chip/lamp bead etc |
Supported Maximum Area of PCB | 350*330mm 50*50mm |
Feeders | NXT electric feeder,vibration feeder,IC tray etc |
Recognition Devices | Mark camera ----------------------2
High-precision camera -------1
Fast recognition camera -----8
|
Maximum Height of Applicable Components | |
Recognition Methods | Simultaneous recognition and picking with four heads |
PCB Convey Mode | Three-stage entry, automatic connection from left to right, automatic PCB |
Mark Positioning | Manual/ Automatic |
Programming Method | Automatic programming after manually importing files of PCB coordinates |
Control System | Control system of our own design |
Maximum Step Lenqth of XY Axis | 423mm*734mm(Left)
423mm*734mm (Right) |
Tracks of XY Axis | Four linear motion quide + four ground ball screw |
Motion Mode of XY Axis | Intelligent linkage of acceleration and deceleration of curve and line, integrated linear interpolation algorithm. |
Control Computer
| Industrial control computer with Intel high-performance processorindustrial control computer with Intel high-performance processor |
Adjusting Method of Tracks | Electric |
Range of Nozzle Buffer | 4.5mm |
Maximum Step length of Z Axis | 50mm |
Maximum Step Length of Z Axis | Resistor/capacitor/chip/lamp bead etc |
Range of Angle for Components | 士180° |
Motor | Imported AC Servo Motor MINAS A6 series |
Driver | Imported high-speed DSP driver |
Air Supply Requirements | Oil water filter> 60L,dust filter and air pressure stabilizer etc |
Vacuum Supply of Nozzle | Japanese CKD vacuum generator integrating the high.speed vacuum burst function |
Range of Air Supply Pressure | 0.5-0.6mp |
Vision Display | 17-inch industrial control display |
Os | Independent research and development SMT intelligent OS based on Windows |
Cable | German lgus durable flexible cable(10 million times) |
Power Supply | 220V 50/60Hz |
Average Power | 1500W |
Machine Dimensions | 1740*1360*1440mm |
Weight | 1100Kg |
